Aquapro 8000GPD 4 x 4040 Industrial Reverse Osmosis Filtration System with Grundfos Digital Controller & Recycle
| DOWNLOAD USER MANUAL |
FEATURES
- Concentrate Flow Meter – 1-10GPM (35 lpm)
- Permeate Flow Meter – 1-10GPM (35 lpm)
- Recycle Flow Meter – 1-5GPM (18 lpm)
- Source Water Pressure Gauge – 0-200PSI
- RO Outlet Water Pressure Gauge – 0-500PSI
- Low Pressure Switch
- 1” Inlet Actuator
- 1/2” Flush Solenoid Valve
- Recycle 1/2" Stainless Steel Gate Valve
- Concentrate 1/2" Stainless Steel Gate Valve
- Check Valve in Recycle Valve
- Power On/Off Switch
- Provisions for a Float Switch (Not supplied)
- Temperature monitoring
- Conductivity monitoring with over limit alarm
- Adjustable Flush Time sequence
- TDS monitoring
- Indicator lights for
- Low Feed Pressure
- Low Pressure
- High Pressure
- Tank Full
- Auto Flush
- 3 ½” LED digital display
SPECIFICATIONS
| Performance | @ 25°C, 2000ppm TDS* |
| Feed flow | 4.0 m³/hr |
| Permeate flow | 1.20 m³/hr |
| Recovery | Up to 50% |
| Rejection | 95 - 98% |
| Operating pressure | 200 psi max |
| Inlet pressure | 40 - 90 psi max |
| Temperature | 45°C max |
| Membrane housing | 4 x 4040 Fibreglass |
| Membrane | 4 x RE-4040-BE CSM |
| Pre-filtration | 20” x 4.5” |
| 1 x 5 µm Sediment | |
| 1 x 10 µm Carbon | |
| Pump & Motor | Grundfos |
| CR1-23 X-P-A-E HQQE | |
| 2.2 kw 240V 50 hz | |
| Piping | High pressure reinforced |
| Electrical | 1.65 m power cord with 15A plug |
| Controller | ROC 2315 Microprocessor |
| Frame | Stainless Steel |
| Connections | 1 1/4” Inlet, 1” M Concentrate, |
| 1” M Permeate & 1/2” M Comp | |
| Brine | |
| Dimensions | 1420 H x 950 W x 1030 D |
